32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope

Name: 32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope
Brand: Haiye
Price: 1000 USD

32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope Manufactures

Brand Name : Haiye

Model Number : HYHJ-KC

Certification : CE ,ISO13485 ,FDA

Place of Origin : China

MOQ : 1 set

Price : USD1000/USD1500 /Set

Payment Terms : L/C, T/T, D/A

Supply Ability : 1000 sets

Delivery Time : 5-8 days after your payment

Packaging Details : Carton

Product name : Video Laryngoscope

Pixel : 2 Million

Resolution : 960*480

Depth of Field : 3-100mm

Material : Stainless steel

Color : silver gray

Reusable blade : 5 blades

Battery : Rechargeable Lithium Battery

USB storage Card : 8GB to 32 GB

Battery Working time : >400mins

Cycle working times : >600 times

Warranty : 1 year

Field angle : 70+2

Contact Now

NEW Medical Device Emergency Department Use Video Laryngoscope

Specifications for the Video Laryngoscope

Product Name:	Video Laryngoscope	Screen:	3.0 Inch
Resolution:	960*480	Pixel:	2 Million
Blade:	Difficulty -blade ,Large-adult ,Medium-adult ,Pediatric ,Neonate	Image / Video:	Yes
USB Starage Card:	8GB To 32 GB	Certificate:	CE ,FDA ,ISO13485
Battery:	Rechargeable Lithium Battery	Battery Working Time:	> 400 Hrs
Cycle Working Times:	> 600 Times	Warranty:	1 Year

Model No.: HYHJ-KC

Reusable blade : 1. Difficulty-blade 2. Large-Adult 3. Medium-adult 4. Pediatric 5. Neonate

PARTS	Description	Technical Index
Machine	Screen	3 inch LCD
	Resolution	960*480 (RGB)
	Viewing angle	≥70º
	Power	<2W
	Display front and back rotation Angle	0 º~175 º
	Weight	225g
Camera	Illuminance	≥3000 LUX
Camera	Resolution	1280*720 px
Image/Video function	Image/ Video function	Yes
	Output	USB output, Easy to storage and establish image/video
	Memory type	Micro SD card 32GB
Battery	Battery Type	Rechargable lithium battery
	Capacity	3400mAh
	Cycle life of battery	>600 times
	Battery working time	>400min
	Charging time	<2(hrs)
	Charging Port	Micro USB
Power Adapter	Input	100-250V, 50 Hz.
Power Adapter	Output	5V1A
Working Condition	Temperature	-5℃~+50℃
	Humidity	10%~90%
	Air Pressure	860~1060hpa
Transport / Storage Condition	Temperature	-10℃~50℃
	Humidity	≤93%
	Air Pressure	500~1060hpa

Video Laryngoscope Features:

*Anti fog coating on distal lens
*Video/Photo function
*Battery rechargeable
*One button Only, Fast and simple operation
*360 °All sight LCD, no blind spot

*Video Laryngoscope Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.

Video Laryngoscope Advantages

**Portable

Light weight, main unit is less than 350g. easy to install or remove. It's ready to use in no time.

Video Laryngoscope Packing and Delivery

Packing Size :400*95*360mm

Package Type :Carton ,Standard Export Packing for Ansthesia Video Laryngoscope With 5 blades.

32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope

Haiye Video Laryngoscope Package

32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope

Haiye Video Laryngoscope workshop

32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope

Haiye Video Laryngoscope Certificate

32 GB Medical Surgical Endoscope Equipment Portable Video Laryngoscope
